Conf ig ur in g Di amet er Cli ent Nod es an d Re lay Ag ent s
Table 4-2 Diameter Node General Configuration Properties
Property Name Description
Dynamic Peers
Allowed Select this option to allow dynamic discovery of Diameter peer nodes. Dynamic
peer support is disabled by default. BEA recommends enabling dynamic
peers only when using the TLS transport, because no access control
mechanism is available to restrict hosts from becoming peers.
Peer Retry
Delay Enter the amount of time, in seconds, this node waits before retrying a request to a
Diameter peer. The default value is 30 seconds.
Request
Timeout Enter the amount of time, in milliseconds, this node waits for an answer message
before timing out.
Watchdog
Timeout Enter the number of seconds this node uses for the value of the Diameter Tw
watchdog timer interval.
Targets Enter one or more target engine tier server names. The Diameter node configuration
only applies to servers listed in this field.
Default Route
Action Specify an action type that describes the role of this Diameter node when using a
default route. The value of this element can be one of the following:
Default Route
Servers
• none
• local
• relay
• proxy
• redirect
Specifies one or more target servers for the default route. Any server you
include in this element must also be defined as a peer to this Diameter node,
or dynamic peer support must be enabled.
6. Click Activate Changes to apply the configuration to target servers.
After creating a general node configuration, the configuration name appears in the list of
Diameter nodes. You can select the node to configure Diameter applications, peers, and routes,
as described in the sections that follow.
Configuring Diameter Applications
Each Diameter node can deploy one or more applications. You configure Diameter applications
in the Administration Console using the Configuration->Applications page for a selected
Diameter node. Follow these steps:
