En ab lin g th e Dia met er Console Extensio n Enabling the Diameter Console Extension WebLogic SIP Server provides a console extension to help you create and configure Diameter nodes. The actual configuration generated by the extension is stored in a diameter.xml configuration file, stored in the config/custom subdirectory of the domain directory. The sample Diameter domain already enables the Diameter console extension. If you are working with a domain that does not enable the extension, edit the config.xml file for the domain to specify the custom resource for the extension. Listing 4-1 highlights the config.xml entries necessary to enable the console extension. Use a text editor to add the highlighted lines in the correct location in config.xml . Listing 4-1 config.xml Entries for Enabling the Diameter Console Extension sipserver hssclient custom/sipserver.xml com.bea.wcp.sip.management.descriptor.resource.SipServerRe source com.bea.wcp.sip.management.descriptor.beans.SipServ erBean diameter hssclient,relay,hss 200 custom/diameter.xml com.bea.wcp.diameter.DiameterResource Configuring Network Resources 4-5
