Instal ling the Diameter Domai n
The sections that follow describe each step in detail. See also the “Example Domain
Configuration” on page 4-21.
Installing the Diameter Domain
The Configuration Wizard includes a Diameter domain template that creates a domain having
four WebLogic SIP Server instances:
– An Administration Server (AdminServer)
– A Diameter Sh client node (hssclient)
– A Diameter relay node (relay)
– An HSS simulator (hss)
You can use the installed Diameter domain as the basis for creating your own domain. Or, you
can use the customized Diameter Web Applications as templates for configuring existing
WebLogic SIP Server instances to function as HSS client or relay agent nodes. The configuration
instructions in the sections that follow assume that you have access to the Diameter domain
configuration. Follow these steps to install the domain:
1. Change to the WLSS_HOME\common\bin directory, where WLSS_HOME is the directory in
which you install WebLogic SIP Server (for example, c:\bea\sipserver31\common\bin ).
2. Execute the config.cmd or config.sh script to launch the Configuration Wizard.
3. Select Create a new WebLogic Domain and click Next.
4. Select Base this domain on an existing template, and click the Browse button.
5. Select the diameterdomain.jar template and click OK.
6. Click Next.
7. Enter a username and password for the Administrator of the new domain, and click Next.
8. Select the startup mode and JDKs to use with the new domain, and click Next.
9. Select No to accept the default template options, and click Next.
10. Click Create to create th e new domain using the default domain name and domain location
( BEA_HOME/user_projects/domains/diameter ).
11. Click Done.
