Example WebLogic SIP Server Network Configuration
Session Initiation Protocol Request-Line: SUBSCRIBE sip: subscribe @ 1.2.3.4:5060 SIP / 2.0 Message Header Via: SIP / 2.0 / UDP 2.3.4.5:9999; maddr = 2.3.4.5; branch = 1 From: sipp < sip: sipp @ 2.3.4.5 >; tag = 1 To: sut < sip: subscribe @ 1.2.3.4:5060 > Call-ID: 1-25923 @ 2.3.4.5 Cseq: 1 SUBSCRIBE Contact: sip: sipp @ 2.3.4.5:9999 Max-Forwards: 70 Event: ua-profile Expires: 10 Content-Length: 0
No. Time Source Destination Protocol Info 3 3.430903 10.1.1.1 2.3.4.5 SIP Status: 200 OK
Internet Protocol, Src: 10.1.1.1( 10.1.1.1), Dst: 2.3.4.5( 2.3.4.5) User Datagram Protocol, Src Port: 42316( 42316), Dst Port: 9999( 9999) Session Initiation Protocol Status-Line: SIP / 2.0 200 OK Message Header To: sut < sip: subscribe @ 1.2.3.4:5060 >; tag = 82722c03 Content-Length: 0
Contact: < sip: app-12eomtm5h5f77 @ 1.2.3.4:5060; transport = udp; wlsscid = 1ae4479ac6ff71 >
3-14 Configuring Network Resources
