Exa mple We bLo gic S IP Ser ver Ne two rk Con fi gu ra ti on
Session Initiation Protocol
Request-Line: SUBSCRIBE sip:subscribe@1.2.3.4:5060 SIP/2.0
Message Header
Via: SIP/2.0/UDP 2.3.4.5:9999;branch=1
From: sipp ;tag=1
To: sut
Call-ID: 1-25923@2.3.4.5
Cseq: 1 SUBSCRIBE
Contact: sip:sipp@2.3.4.5:9999
Max-Forwards: 70
Event: ua-profile
Expires: 10
Content-Length: 0
No.
Time Source
3 3.430903 10.1.1.1
Destination
2.3.4.5
Protocol Info
SIP
Status: 200 OK
Internet Protocol, Src: 10.1.1.1 (10.1.1.1), Dst: 2.3.4.5 (2.3.4.5)
User Datagram Protocol, Src Port: 42316 (42316), Dst Port: 9999 (9999)
Session Initiation Protocol
Status-Line: SIP/2.0 200 OK
Message Header
To: sut ;tag=82722c03
Content-Length: 0
Contact:
CSeq: 1 SUBSCRIBE
Call-ID: 1-25923@2.3.4.5
3-6
Configuring Network Resources
