Drills Morse Taper Accessories
Morse Taper Sleeve
- Hardened alloy steel
- Precision ground internally and externally
Drill Drift key - to eject Morse Taper drills from sleeves, sockets and machine spindles
Outside Morse
Morse Taper
Taper
Outside
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Point Type
Shank Tolerance
Inside
Taper
Inside Morse
Morse
Taper
a
Size Ref.
0012
0013
0023
0014
0024
0034
0015
0025
0035
0045
0036
0046
0056
(external) d 1 l 1 a 1 d 2
1 2 17.780 92 17 12.065
1 3 23.825 99 5 12.065
2 3 23.825 112 18 17.78
(1)* 4 31.267 124 6.5 12.065
2 4 31.267 124 6.5 17.78
3 4 31.267 140 22.5 23.825
(1)* 5 44.399 156 6.5 12.065
(2)* 5 44.399 156 6.5 17.78
3 5 44.399 156 6.5 23.825
4 5 44.399 171 21.5 31.267
3 6 63.348 218 8 23.825
4 6 63.348 218 8 31.267
5 6 63.348 218 8 44.399
MT #1 & #2
MT #3
MT #4
MT #5 & #6
D118
A0702
- Alloyed Steel
Brt Brt
Drift Sleeve
- -
- -
- -
Item #
Item #
D118 0012
D118 0013
D118 0023
D118 0014
D118 0024
D118 0034
D118 0015
D118 0025
D118 0035
D118 0045
D118 0036
D118 0046
D118 0056
D142 MT1
D142 MT3
D142 MT4
D142 MT5
www.klte.cz
MT1
MT3
MT4
MT5
(internal) MT #
MT #
D142 A0702
118
*The use of sizes where inside taper is shown in brackets should be avoided wherever possible
