SUTTON - katalog | KL-TECH s.r.o. | www.klte.cz SUTTON_katalog | Page 397

Reamers Taper Pipe
- For use by hand with suitable wrench
- Suitable for tool rooms & workshop use
- Used prior to tapping tapered thread forms 1:16 taper (BSPT, NPT)
- Prolongs tap life, especially in tough materials
d 2
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
d 3
Size
0803
1031
1372
1689
2225
2802
3668
4277
5484 1/8
1/4
3/8
1/2
3/4
1
1-1/4
1-1/2
2
B0302
HSS
Brt
Tapered Pipe
L15
d 1 l 1 l 2 d 2 d 3 z Item #
8.00 60 15 8.00 8.97 6 10.31 67 20 10.00 11.50 6 13.72 75 22 12.50 15.63 6 16.89 87 26 16.00 18.52 6 R108 0803
R108 1031
R108 1372
R108 1689
R108 2225
R108 2802
R108 3668
R108 4277
R108 5484
22.25 96 29 20.00 24.00 6
28.00 110 33 25.00 30.08 6
36.58 119 37 31.50 38.83 6
42.77 125 37 35.50 15.08 8
54.84 140 41 40.00 57.40 8
