Slot Drills 2 Flute, R40 Cu, Regular
- For precision milling of slots & cavities
- Optimised for Copper & Copper Alloys
- CrN for superior finish and tool life in copper
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Shank Form (DIN 1835)
Shank Tolerance
(h9)
Size Ref.
d 1 (e8)
0300
0400
0500
0600
0800
1000
1200
1600
HSS Co.8
CrN
Cu
R40
B
h6
l 1 l 2 d 2 z Item #
52 8 6 2 55 11 6 2 57 13 6 2 57 13 6 2 69 19 10 2 72 22 10 2 83 26 12 2 92 32 16 2 E211 0300
E211 0400
E211 0500
E211 0600
E211 0800
E211 1000
E211 1200
E211 1600
www.klte.cz
3.0
4.0
5.0
6.0
8.0
10.0
12.0
16.0
E211
B0608
P
1
2
3
4
5
6
7
M
8
K
N
392
Steel
E211
P
M
Stainless Steel
K
Cast Iron
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
N
Non-Ferrous Metals
S
Titanium & Super Alloys
H
Hard Materials
ISO
VDI 3323
• Optimal • Effective
