Slot Drills Carbide, 2 Flute, R30 UNI, Long Reach, Harmony
- VHM-ULTRA grade of carbide for high performance
- For precision milling of slots & cavities
- Suitable for materials up to 1600 N/mm 2
- AlCrN for longer tool life
+
45º
6º
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Shank Form (DIN 6535)
Shank Tolerance
3
3
Size Ref.
d 1 (e8)
0200
0250
0300
0350
0400
0450
0500
0550
0600
0700
0800
0900
1000
1100
1200
1300
1400
1500
1600
1800
2000
E419
B0210
VHM-ULTRA VHM-ULTRA
AlCrN AlCrN
UNI UNI
R30 R30
HA HB
h5 h5
l 1 l 2 l 3 d 2 d 3 z Item # Item #
54 3 9 6 1.8 2 54 3.5 9 6 2.2 2 54 4 11 6 2.7 2 57 4.5 11 6 3.1 2 57 5 15 6 3.6 2 57 5.5 15 6 4.1 2 62 6 23 6 4.5 2 62 6.5 23 6 5.0 2 62 7 24 6 5.4 2 68 8 28 8 6.3 2 68 9 30 8 7.2 2 80 10 36 10 8.2 2 80 11 38 10 9.0 2 93 12 44 12 10.0 2 93 13 46 12 11.0 2 93 14 44 14 12.0 2 93 15 46 14 13.0 2 108 16 56 16 14.0 2 108 17 58 16 15.0 2 108 19 58 18 17.0 2 126 21 74 20 19.0 2 E418 0200
E418 0250
E418 0300
E418 0350
E418 0400
E418 0450
E418 0500
E418 0550
E418 0600
E418 0700
E418 0800
E418 0900
E418 1000
E418 1100
E418 1200
E418 1300
E418 1400
E418 1500
E418 1600
E418 1800
E418 2000 E419 0200
E419 0250
E419 0300
E419 0350
E419 0400
E419 0450
E419 0500
E419 0550
E419 0600
E419 0700
E419 0800
E419 0900
E419 1000
E419 1100
E419 1200
E419 1300
E419 1400
E419 1500
E419 1600
E419 1800
E419 2000
