Endmills Carbide, Ballnose, 4 Flute, R30 N, Extra Long
- For profile & contour milling in extra long reach applications- Suitable for materials up to 1300 N / mm 2- Minimal deflection due to strong / larger core
+
12 º
Catalogue Code
E320
Discount Group
B0208
Material
VHM
Surface Finish
Brt
Sutton Designation
N
Geometry
R30
Shank Form( DIN 6535)
HA
Shank Tolerance
h6
Size Ref.
d 1
( h10)
l 1
l 2
d 2
z
Item #
0300
3.0
76
25
3
4
E320 0300
0400
4.0
76
28
4
4
E320 0400
0500
5.0
76
32
5
4
E320 0500
0600
6.0
102
38
6
4
E320 0600
0800
8.0
102
42
8
4
E320 0800
1000
10.0
102
45
10
4
E320 1000
1200
12.0
153
76
12
4
E320 1200
1400
14.0
153
76
14
4
E320 1400
1600
16.0
153
76
16
4
E320 1600
1800
18.0
153
76
18
4
E320 1800
2000
20.0
153
76
20
4
E320 2000
KL-TECH s. r. o | www. klte. cz
ISO
VDI 3323
E320
1 2
3 4
5 6
P 7
8 9
M 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
K N
•
•
S
•
•
•
•
•
H
•
P Steel M Stainless Steel K Cast Iron N Non-Ferrous Metals S Titanium & Super Alloys H Hard Materials
• Optimal • Effective
