Endmills Carbide, 3 Flute, R30 N, DIN6527L
- Universal use for slotting and finishing with the one tool
- Suitable for materials up to 1600 N/mm 2
- TiAlN for longer tool life
+
12º
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Shank Form (DIN 6535)
Shank Tolerance
Size Ref.
d 1 (h10)
0300
0350
0400
0450
0500
0600
0700
0800
0900
1000
1200
1400
1600
1800
2000
E514 E515 E516
B0208 B0210 B0210
VHM VHM VHM VHM
Brt Brt TiAlN TiAlN
N N N N
R30 R30 R30 R30
HA HB HA HB
h6 h6 h6 h6
l 1 l 2 d 2 z Item # Item # Item # Item #
57 7 6 3 57 7 6 3 57 8 6 3 57 8 6 3 57 10 6 3 57 10 6 3 63 13 8 3 63 16 8 3 72 16 10 3 72 19 10 3 83 22 12 3 83 22 14 3 92 26 16 3 92 26 18 3 104 32 20 3 E513 0300
E513 0350
E513 0400
E513 0450
E513 0500
E513 0600
E513 0700
E513 0800
E513 0900
E513 1000
E513 1200
E513 1400
E513 1600
E513 1800
E513 2000 E514 0300
•
E514 0400
•
E514 0500
E514 0600
E514 0700
E514 0800
E514 0900
E514 1000
E514 1200
E514 1400
E514 1600
E514 1800
E514 2000 E515 0300
•
E515 0400
•
E515 0500
E515 0600
E515 0700
E515 0800
E515 0900
E515 1000
E515 1200
E515 1400
E515 1600
E515 1800
E515 2000 E516 0300
•
E516 0400
•
E516 0500
E516 0600
E516 0700
E516 0800
E516 0900
E516 1000
E516 1200
E516 1400
E516 1600
E516 1800
E516 2000
