DIN Taps Metric Fine, Spiral Flute, R50 VA PM
- Use in stainless steels and high strength steels up to 1000N / mm 2- PM-HSSE V3 offers higher edge hardness than standard VA series- Blind holes- Suitable for synchronous tapping in machine operations- Depths up to approx. 3 x d 1
Catalogue Code
T250
T252
Discount Group
D0402
D0408
Material
PM-HSSE V3
PM-HSSE V3
Surface Finish
Blu
TiCN
Sutton Designation
VA PM
VA PM
Geometry
R50
R50
Chamfer
Form C / 2.5 x P
Form C / 2.5 x P
Limit & Nut Tolerance
6HX
6HX
Size Ref.
d 1
Pitch
l 1
l 2
l 3
d 2
sq
l 4
z
drill ø
Item #
Item #
0302
MF 3
x 0.35
56
4
-
2.2
-
-
3
2.65
T250 0302
•
0403
MF 4
x 0.5
63
6
-
2.8
2.1
5
3
3.5
T250 0403
•
0503
MF 5
x 0.5
70
7
-
3.5
2.7
6
3
4.5
T250 0503
•
0604
MF 6
x 0.75
80
8
-
4.5
3.4
6
3
5.3
T250 0604
T252 0604
0803
MF 8
x 0.5
80
10
-
6.0
4.9
8
3
7.5
T250 0803
T252 0803
0804
MF 8 x 0.75
80
10
-
7.0
4.9
8
3
7.3
• •
0805
MF 8
x 1
90
8
-
6.0
4.9
8
3
7.0
T250 0805
T252 0805
1004
MF 10 x 0.75
90
10
-
7.0
5.5
8
3
9.3
T250 1004
T252 1004
1005
MF 10 x 1
90
10
-
7.0
5.5
8
3
9.0
T250 1005
T252 1005
1006
MF 10 x 1.25
100
13
-
7.0
5.5
8
3
8.8
T250 1006
T252 1006
1205
MF 12 x 1
100
14
-
9.0
7.0
10
3
11.0
T250 1205
T252 1205
1206
MF 12 x 1.25
100
14
-
9.0
7.0
10
3
10.8
T250 1206
T252 1206
1207
MF 12 x 1.5
100
14
-
9.0
7.0
10
3
10.5
T250 1207
T252 1207
1405
MF 14 x 1
100
16
-
11.0
9.0
12
3
13.0
T250 1405
T252 1405
1406
MF 14 x 1.25
100
16
-
11.0
9.0
12
3
12.8
T250 1406
T252 1406
1407
MF 14 x 1.5
100
16
-
11.0
9.0
12
3
12.5
T250 1407
T252 1407
1605
MF 16 x 1
100
16
-
12.0
9.0
12
3
15.0
T250 1605
T252 1605
1607
MF 16 x 1.5
100
16
-
12.0
9.0
12
3
14.5
T250 1607
T252 1607
1805
MF 18 x 1
110
20
-
14.0
11.0
14
4
17.0
• T252 1805
1807
MF 18 x 1.5
110
20
-
14.0
11.0
14
4
16.5
T250 1807
T252 1807
1808
MF 18 x 2
125
20
-
14.0
11.0
14
4
16.0
2005
MF 20 x 1
125
20
-
16.0
12.0
15
4
19.0
• T252 2005
2007
MF 20 x 1.5
125
20
-
16.0
12.0
15
4
18.5
T250 2007
T252 2007
2008
MF 20 x 2
140
20
-
16.0
12.0
15
4
18.0
• •
KL-TECH s. r. o | www. klte. cz MF
ISO
VDI 3323
T250 T252
1 2
3 4 5
• •
• •
• •
•
6
P 7
8 9
• •
• •
•
10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
•
• •
• •
• •
• •
P Steel M Stainless Steel K Cast Iron N Non-Ferrous Metals S Titanium & Super Alloys H Hard Materials
M K
N
•
•
•
•
•
•
•
•
•
S
H
• Optimal • Effective
245
• Available on request as special manufacture. Subject to lead time.
