DIN Taps Metric Fine, Gun, NH
- Suitable for harder materials up to 42 HRc
- Through holes
- Suitable for machine operations
- Depths up to approx. 3 x d 1
d 1 Pitch l 1 l 2 l 3 d 2 sq l 4 z drill ø
MF 3
MF 4
MF 5
MF 6
MF 8
MF 8
MF 8
MF 10
MF 10
MF 10
MF 12
MF 12
MF 12
MF 14
MF 14
MF 14
MF 16
MF 16
MF 18
MF 18
MF 18
MF 20
MF 20
MF 20 x 0.35
x 0.5
x 0.5
x 0.75
x 0.5
x 0.75
x 1
x 0.75
x 1
x 1.25
x 1
x 1.25
x 1.5
x 1
x 1.25
x 1.5
x 1
x 1.5
x 1
x 1.5
x 2
x 1
x 1.5
x 2 56 8 - 2.2 - - 3 2.65
63 10 - 2.8 2.1 5 3 3.5
70 12 - 3.5 2.7 6 3 4.5
80 14 - 4.5 3.4 6 3 5.3
80 18 - 6.0 4.9 8 3 7.5
80 18 - 6.0 4.9 8 3 7.3
90 22 - 6.0 4.9 8 3 7.0
90 20 - 7.0 5.5 8 3 9.3
90 20 - 7.0 5.5 8 3 9.0
100 24 - 7.0 5.5 8 3 8.8
100 22 - 9.0 7.0 10 3 11.0
100 22 - 9.0 7.0 10 3 10.8
100 22 - 9.0 7.0 10 3 10.5
100 22 - 11.0 9.0 12 3 13.0
100 22 - 11.0 9.0 12 3 12.8
100 22 - 11.0 9.0 12 3 12.5
100 22 - 12.0 9.0 12 3 15.0
100 22 - 12.0 9.0 12 3 14.5
110 25 - 14.0 11.0 14 4 17.0
110 25 - 14.0 11.0 14 4 16.5
125 34 - 14.0 11.0 14 4 16.0
125 25 - 16.0 12.0 15 4 19.0
125 25 - 16.0 12.0 15 4 18.5
140 34 - 16.0 12.0 15 4 18.0
Size Ref.
T654 T163
D0402 D0410
PM-HSSE V3 PM-HSSE V3
Blu TiAlN
NH NH
Form B / 4.5 x P Form B / 4.5 x P
ISO2 / 6H ISO2 / 6H
Item # Item #
•
•
•
•
•
•
T654 0805
•
T654 1005
•
•
T654 1206
•
•
•
•
•
•
•
•
•
•
•
• T163 0302
T163 0403
T163 0503
T163 0604
T163 0803
T163 0804
T163 0805
T163 1004
T163 1005
T163 1006
T163 1205
T163 1206
T163 1207
T163 1405
T163 1406
T163 1407
T163 1605
T163 1607
T163 1805
T163 1807
T163 1808
T163 2005
T163 2007
T163 2008
www.klte.cz
0302
0403
0503
0604
0803
0804
0805
1004
1005
1006
1205
1206
1207
1405
1406
1407
1605
1607
1805
1807
1808
2005
2007
2008
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
P
238
P
Steel
M
Stainless Steel
K
6
7
M
8
K
N
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
Cast Iron
N
Non-Ferrous Metals
S
• Available on request as special manufacture. Subject to lead time.
Titanium & Super Alloys
H
Hard Materials
5
4
3
T654
T163
2
1
ISO
VDI 3323
• Optimal • Effective
