DIN Taps Metric, Forming, UNI
- SPM for superior performance- Application specific geometry- Suitable for materials with > 10 % elongation- Through or blind holes- Depths up to 3 x d 1
Catalogue Code
T325
T751
T327
Discount Group
D0410
D0410
D0410
Material
SPM
SPM
SPM
Surface Finish
TiAlN
TiAlN
TiAlN
Sutton Designation
UNI
UNI
UNI
Geometry
Multi-Coolant Groove
Multi-Coolant Groove
IK
Chamfer
Form C / 2.5 x P
Form E / 1.5 x P
Form C / 2.5 x P
Limit & Nut Tolerance
6HX
6HX
6HX
Size Ref.
d 1
Pitch
l 1
l 2
l 3
d 2
sq
l 4
z
drill ø
Item #
Item #
Item #
0200
M 2
x 0.4
45
6
-
2.8
2.1
5
1.8
T325 0200
0220
M 2.2 x 0.45
45
7
-
2.8
2.1
5
2.0
•
0230
M 2.3 x 0.4
45
7
-
2.8
2.1
5
2.1
•
0250
M 2.5 x 0.45
50
8
-
2.8
2.1
5
2.3
T325 0250
0260
M 2.6 x 0.45
50
8
-
2.8
2.1
5
2.4
•
0300
M 3
x 0.5
56
9
18
3.5
2.7
6
2.8
T325 0300
•
0350
M 3.5 x 0.6
56
11
20
4.0
3.0
6
3.2
•
0400
M 4
x 0.7
63
12
21
4.5
3.4
6
3.7
T325 0400
•
0500
M 5 x 0.8
70
13
25
6.0
4.9
8
4.6
T325 0500
• T327 0500
0600
M 6 x 1
80
15
30
6.0
4.9
8
5.5
T325 0600
• T327 0600
0800
M 8 x 1.25
90
18
35
8.0
6.2
9
7.4
T325 0800
• T327 0800
1000
M 10 x 1.5
100
20
39
10.0
8.0
11
9.3
T325 1000
• T327 1000
M
Size Ref. d 1 Pitch l 1 l 2 l 3 d 2 sq l 4 z drill ø Item # Item # Item #
T326 T752 T328
1200 M 12 x 1.75 110 23- 9.0 7.0 10 11.2 T326 1200 • T328 1200
1400 M 14 x 2 110 25- 11.0 9.0 12 13.1 T326 1400 • T328 1400
1600 M 16 x 2 110 25- 12.0 9.0 12 15.1 T326 1600 • T328 1600
1800 M 18 x 2.5 125 30- 14.0 11.0 14 16.9 • • •
2000 M 20 x 2.5 140 30- 16.0 12.0 15 18.9 • • •
