DIN Taps Metric, Spiral Flute, R50 VA PM
- Universal high performance tapping- PM-HSSE V3 offers superior tool life- Use in stainless steels and high strength steels up to 850N / mm 2- Deep blind holes- Depths up to 3 x d 1
Catalogue Code
T203
T205
T678
T676
Discount Group
D0402
D0408
D0408
D0408
Material
PM-HSSE V3
PM-HSSE V3
PM-HSSE V3
PM-HSSE V3
Surface Finish
Blu
TiCN
TiCN
TiCN
Sutton Designation
VA PM
VA PM
VA PM
VA PM
Geometry
R50
R50
R50
R50
Chamfer
Form C / 2.5 x P
Form C / 2.5 x P
Form C / 2.5 x P
Form E / 1.5 x P
Limit & Nut Tolerance
6HX
6HX
6GX
6HX
Size Ref.
d 1
Pitch
l 1
l 2
l 3
d 2
sq
l 4
z
drill ø
Item #
Item #
Item #
Item #
0160
M 1.6 x 0.35
40
8
-
2.5
2.1
5
3
1.25
• T205 0160
• •
0200
M 2 x 0.4
45
8
-
2.8
2.1
5
3
1.6
• T205 0200
T678 0200
•
0220
M 2.2 x 0.45
45
9
-
2.8
2.1
5
3
1.75
• • • •
0230
M 2.3 x 0.4
45
9
-
2.8
2.1
5
3
1.9
• • • •
0250
M 2.5 x 0.45
50
9
-
2.8
2.1
5
3
2.05
• T205 0250
T678 0250
•
0300
M 3
x 0.5
56
5
18
3.5
2.7
6
3
2.5
T203 0300
T205 0300
T678 0300
T676 0300
0350
M 3.5 x 0.6
56
6
20
4.0
3.0
6
3
2.9
• T205 0350
T678 0350
T676 0350
0400
M 4
x 0.7
63
7
21
4.5
3.4
6
3
3.3
T203 0400
T205 0400
T678 0400
T676 0400
0500
M 5
x 0.8
70
8
25
6.0
4.9
8
3
4.2
T203 0500
T205 0500
T678 0500
T676 0500
0600
M 6
x 1
80
10
30
6.0
4.9
8
3
5.0
T203 0600
T205 0600
T678 0600
T676 0600
0800
M 8
x 1.25
90
12.5
35
8.0
6.2
9
3
6.8
T203 0800
T205 0800
T678 0800
T676 0800
1000
M 10 x 1.5
100
15
39
10.0
8.0
11
3
8.5
T203 1000
T205 1000
T678 1000
T676 1000
M
Size Ref. d 1 Pitch l 1 l 2 l 3 d 2 sq l 4 z drill ø Item # Item # Item # Item #
T204
T206
T679
T677
1200
M 12 x 1.75
110
17.5
-
9.0
7.0
10
3
10.2
T204 1200
T206 1200
T679 1200
T677 1200
1400
M 14 x 2
110
20
-
11.0
9.0
12
3
12.0
T204 1400
T206 1400
T679 1400
T677 1400
1600
M 16 x 2
110
20
-
12.0
9.0
12
4
14.0
T204 1600
T206 1600
T679 1600
T677 1600
1800
M 18 x 2.5
125
25
-
14.0
11.0
14
4
15.5
T204 1800
T206 1800
T679 1800
T677 1800
2000
M 20 x 2.5
140
25
-
16.0
12.0
15
4
17.5
T204 2000
T206 2000
T679 2000
T677 2000
2200
M 22 * x 2.5
140
25
-
18.0
14.5
17
4
19.5
T204 2200
T206 2200
T679 2200
T677 2200
2400
M 24 * x 3
160
30
-
18.0
14.5
17
4
21.0
T204 2400
T206 2400
T679 2400
T677 2400
2700
M 27 * x 3
160
30
-
20.0
16.0
19
4
24.0
T204 2700
T206 2700
• •
3000
M 30 * x 3.5
180
35
-
22.0
18.0
21
4
26.5
T204 3000
T206 3000
• •
ISO
VDI 3323
T203 T205 T678 T676
1 2
3 4 5
• • • •
• • • •
• • • •
• • •
6
P 7
8 9
• • • •
• • • •
• • •
10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
• • •
• • • •
• • • •
• • • •
• • • •
P Steel M Stainless Steel K Cast Iron N Non-Ferrous Metals S Titanium & Super Alloys H Hard Materials
M K
• • •
• • •
• • •
• • •
N
• • •
• • •
• • •
• • •
S
H
• Optimal • Effective
KL-TECH s. r. o | www. klte. cz
215
* HSSE > 20mm • Available on request as special manufacture. Subject to lead time.
