DIN Taps Metric, Spiral Flute, R45 W & Cu
- Suitable for use in soft materials- CrN for copper and non-ferrous materials- Blind holes- Depths up to 3 x d 1
Catalogue Code
T235
T237
T241
T239
Discount Group
D0402
D0402
D0406
D0404
Material
HSSE
HSSE
HSSE
HSSE
Surface Finish
Ni
Blu
TiN
CrN
Sutton Designation
W
W
W
Cu
Geometry
R45
R45
R45
R45
Chamfer
Form C / 2.5 x P
Form C / 2.5 x P
Form C / 2.5 x P
Form C / 2.5 x P
Limit & Nut Tolerance
ISO 2 / 6H
ISO 2 / 6H
ISO 2 / 6H
ISO 2 / 6H
Size Ref.
d 1
Pitch
l 1
l 2
l 3
d 2
sq
l 4
z
drill ø
Item #
Item #
Item #
Item #
0200
M 2 x 0.4
45
8
-
2.8
2.1
5
2
1.6
T235 0200
• • •
0220
M 2.2 x 0.45
45
9
-
2.8
2.1
5
2
1.75
• • • •
0230
M 2.3 x 0.4
45
9
-
2.8
2.1
5
2
1.9
• • • •
0250
M 2.5 x 0.45
50
9
-
2.8
2.1
5
2
2.05
T235 0250
• • •
0260
M 2.6 x 0.45
50
9
-
2.8
2.1
5
2
2.15
• • • •
0300
M 3
x 0.5
56
5
18
3.5
2.7
6
3
2.5
T235 0300
T237 0300
T241 0300
T239 0300
0350
M 3.5 x 0.6
56
6
20
4.0
3.0
6
3
2.9
T235 0350
• T241 0350
•
0400
M 4
x 0.7
63
7
21
4.5
3.4
6
3
3.3
T235 0400
T237 0400
T241 0400
T239 0400
0500
M 5
x 0.8
70
8
25
6.0
4.9
8
3
4.2
T235 0500
T237 0500
T241 0500
T239 0500
0600
M 6
x 1
80
10
30
6.0
4.9
8
3
5.0
T235 0600
T237 0600
T241 0600
T239 0600
0800
M 8
x 1.25
90
12.5
35
8.0
6.2
9
3
6.8
T235 0800
T237 0800
T241 0800
T239 0800
1000
M 10 x 1.5
100
15
39
10.0
8.0
11
3
8.5
T235 1000
T237 1000
T241 1000
T239 1000
M
Size Ref. d 1 Pitch l 1 l 2 l 3 d 2 sq l 4 z drill ø Item # Item # Item # Item #
T236
T238
T242
T240
0600
M 6 x 1
80
10
-
4.5
3.4
6
3
5.0
T236 0600
• T242 0600
T240 0600
0800
M 8 x 1.25
90
12.5
-
6.0
4.9
8
3
6.8
T236 0800
• T242 0800
•
1000
M 10 x 1.5
100
15
-
7.0
5.5
8
3
8.5
T236 1000
• T242 1000
•
1200
M 12 x 1.75
110
17.5
-
9.0
7.0
10
3
10.2
T236 1200
T238 1200
T242 1200
T240 1200
1400
M 14 x 2
110
20
-
11.0
9.0
12
3
12.0
T236 1400
T238 1400
T242 1400
T240 1400
1600
M 16 x 2
110
20
-
12.0
9.0
12
4
14.0
T236 1600
T238 1600
T242 1600
T240 1600
1800
M 18 x 2.5
125
25
-
14.0
11.0
14
4
15.5
T236 1800
T238 1800
T242 1800
T240 1800
2000
M 20 x 2.5
140
25
-
16.0
12.0
15
4
17.5
T236 2000
T238 2000
T242 2000
T240 2000
KL-TECH s. r. o | www. klte. cz
ISO
VDI 3323
T235 T237 T241 T239
1 2
3 4 5
• • •
• • •
• • •
• • •
6
P
• • •
• • •
7 8 9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
P Steel M Stainless Steel K Cast Iron N Non-Ferrous Metals S Titanium & Super Alloys H Hard Materials
• Available on request as special manufacture. Subject to lead time.
M K
• • • •
• • • •
N
• • •
• • •
S
H 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
• Optimal • Effective
