DIN Taps Metric, Gun, NH
- Suitable for harder materials up to 42 HRc- Through holes- Depths up to 3 x d 1
Catalogue Code
T134
T140
T142
Discount Group
D0402
D0410
D0410
Material
PM-HSSE V3
PM-HSSE V3
PM-HSSE V3
Surface Finish
Blu
TiAlN
TiAlN
Sutton Designation
NH
NH
NH
Geometry
IK
Chamfer
Form B / 4.5 x P
Form B / 4.5 x P
Form B / 4.5 x P
Limit & Nut Tolerance
ISO 2 / 6H
ISO 2 / 6H
ISO 2 / 6H
Size Ref.
d 1
Pitch
l 1
l 2
l 3
d 2
sq
l 4
z
drill ø
Item #
Item #
Item #
0200
M 2 x 0.4
45
8
-
2.8
2.1
5
3
1.6
• • •
0220
M 2.2 x 0.45
45
9
-
2.8
2.1
5
3
1.75
• • •
0230
M 2.3 x 0.4
45
9
-
2.8
2.1
5
3
1.9
• • •
0250
M 2.5 x 0.45
50
9
-
2.8
2.1
5
3
2.05
• • •
0260
M 2.6 x 0.45
50
9
-
2.8
2.1
5
3
2.15
• • •
0300
M 3
x 0.5
56
11
18
3.5
2.7
6
3
2.5
T134 0300
T140 0300
•
0350
M 3.5 x 0.6
56
13
20
4.0
3.0
6
3
2.9
• • •
0400
M 4
x 0.7
63
13
21
4.5
3.4
6
3
3.3
T134 0400
T140 0400
•
0500
M 5
x 0.8
70
16
25
6.0
4.9
8
3
4.2
T134 0500
T140 0500
•
0600
M 6
x 1
80
19
30
6.0
4.9
8
3
5.0
T134 0600
T140 0600
T142 0600
0800
M 8
x 1.25
90
22
35
8.0
6.2
9
3
6.8
T134 0800
T140 0800
T142 0800
1000
M 10 x 1.5
100
24
39
10.0
8.0
11
3
8.5
T134 1000
T140 1000
T142 1000
M
Size Ref. d 1 Pitch l 1 l 2 l 3 d 2 sq l 4 z drill ø Item # Item # Item #
T135
T141
T143
1200
M 12 x 1.75
110
28
-
9.0
7.0
10
3
10.2
T135 1200
T141 1200
T143 1200
1400
M 14 x 2
110
30
-
11.0
9.0
12
3
12.0
T135 1400
T141 1400
T143 1400
1600
M 16 x 2
110
32
-
12.0
9.0
12
4
14.0
T135 1600
T141 1600
T143 1600
1800
M 18 x 2.5
125
34
-
14.0
11.0
14
4
15.5
T135 1800
T141 1800
T143 1800
2000
M 20 x 2.5
140
34
-
16.0
12.0
15
4
17.5
T135 2000
T141 2000
T143 2000
2200
M 22 x 2.5
140
34
-
18.0
14.5
17
4
19.5
• • •
2400
M 24 x 3
160
38
-
18.0
14.5
17
4
21.0
• • •
2700
M 27 x 3
160
38
-
20.0
16.0
19
4
24.0
• • •
3000
M 30 x 3.5
180
45
-
22.0
18.0
21
4
26.5
• • •
