SUTTON - katalog | KL-TECH s.r.o. | www.klte.cz SUTTON_katalog | Page 145

ISO Taps BSW, Machine Nut, Long Shank
- Suited to long reach applications
- Suitable for materials up to 1000N/mm 2 m 2
- Through holes
- Depths up to approx. 2 x d 1
d 1
0635
0794
0953
1270
1588
1905
2540
TPI l 1 l 2 l 3 d 2 sq l 4 z drill ø
20
18
16
12
11
10
8 110 38 - 4.5 3.55 6 4 5.1
125 43 - 6 4.5 7 4 6.5
140 48 - 7 5.6 8 4 7.9
180 59 - 9.5 7.5 10 4 10.5
200 70 - 12.5 10.0 13 4 13.5
250 76 - 14 11.2 14 4 16.25
280 95 - 18 14.0 18 4 22.0
HSS
Brt
Nut
-
Bottoming
Z3 Medium
Item #
T465 0635
T465 0794
T465 0953
T465 1270
T465 1588
T465 1905
T465 2540
www.klte.cz
1/4
5/16
3/8
1/2
5/8
3/4
1
T465
D0702
Size Ref.
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
P
Steel
M
Stainless Steel
M
K
Cast Iron
K
N
S
H
