Seat, seatbelt and SRS airbags/Front seatbelt pretensioners
1-19
& Components that will operate with the seatbelt pretensioner(s) simultaneously
Frontal collision
Cases
Side collision
Offset frontal collision Other frontal collision Seatbelt pretensioner for driver * * * *2*3
Shoulder belt pretensioner for front passenger * * * *3*4
Lap belt pretensioner for front passenger * *
Components
SRS frontal airbag
SRS curtain airbag
SRS side airbag
For driver * *
For front passenger *1 * *
Impacted side * Non-impacted side * Impacted side Non-impacted side
Rollover accident
*
– –
– * *
– – *
– – * *5 –
– – – –
*: Operate
–: Not operate
*1
: This does not operate if the occupant detections system deactivates airbag operation. For details, refer to “Front passenger’s SRS frontal airbag” F1-
43
*2
: This operates when both the satellite safing sensor and driver’s side front door impact sensor sense an impact force.
*3
: These do not operate when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals
simultaneously.
*4
: This operates when both the satellite safing sensor and the front passenger’s side front door impact sensor sense an impact force.
*5
: This operates when both the satellite safing sensor and any of the center pillar impact sensors/front door impact sensors sense an impact force.
– CONTINUED –
