6-14
Interior equipment/Rear view camera
& How to use the rear view
camera
When the shift lever (MT models) or select
lever (CVT models) is set to “R”, the rear
view camera automatically displays the
rear view image from the vehicle. When
the lever is set to other positions, the
image before setting to “R” is displayed.
1. Set the ignition switch to “ON”.
2. Set the shift lever (MT models) or
select lever (CVT models) to “R”.
NOTE
. The image of the rear view camera
has priority over other screen displays.
Therefore, while the rear view camera
is in operation, the operations of other
screens are disabled. To operate other
screens, set the shift lever or select
lever to a position other than “R”.
. The image of the rear view camera is
horizontally reversed as is the case
with the vehicle rear view mirror or the
side view mirror.
. It may be difficult to see the image of
the rear view camera in the following
cases. This is not a malfunction of the
camera.
– The vehicle is in a dark place (at
night, in a tunnel, etc.).
– The vehicle is in an extremely hot
or cold place.
– An object (such as raindrops,
snow, dirt, etc.) that disturbs the
view of the rear view camera sticks
to the lens of the camera.
– Strong light shined directly on
the camera lens (occasionally, there
are vertical lines on the screen).
To turn on the rear view image cancel
delay function:
1. Touch the rear view image screen.
! Rear view image cancel delay
function
The rear view image cancel delay function
will keep the rear view image displayed
after shifting the shift lever/select lever out
of the “R” position before the screen
returns to the previous screen.
1)
“Delay” key
2. Touch the “Delay” key.
It is possible to turn on/off the function by
touching the “Delay” key.
NOTE
If the rear view screen is not touched
for 5 seconds, both the “Delay” and
“Display Adjustment” keys will turn off.
Touch the rear view screen to display
the keys again.
When the rear view image cancel delay
function is on, the rear view image screen
can be automatically returned to the
previous screen if any of the following
