5-18
Audio / Audio set
NOTE
. If the audio control screen appears, select the“ Source” key on the audio screen or press the AUDIO / TUNE knob again.. When you push the AUDIO / TUNE knob while any screen other than the audio control screen is displayed, the display will return to the audio control screen.. When the AUDIO / TUNE knob is pushed and held, the graphic equalizer screen will be displayed. Refer to““ Graphic Equalizer”” F5-22.
! Selecting a function menu
Press the HOME button to display home screen.
Item
AUDIO
PHONE
APPS
SETTINGS
Function Select to display the main screen of the audio source that was selected previously.
Select to display the hands-free function using your cell phone. Refer to“ Hands-free phone system” F5-70.
Select to display the functions linked with a smartphone. Refer to“ SUBARU STARLINK” F5- 25.
Select to display the functions for performing various settings. Refer to“ Unit settings” F5-18.
& Unit settings
Sound quality adjustment, screen adjustment, and information of the audio unit are displayed.
1. Press the HOME button on the audio panel.
2. Touch the“ SETTINGS” key. 3. Select the items to be set.
Available setting:
. General settings: Select the tab to check the system software update information. Refer to“ General settings” F5-19.
. Bluetooth settings: Select the tab to set the Bluetooth settings. Refer to“ Bluetooth settings” F5-19.
. Sound settings: Select the tab to set the sound quality settings. Refer to“ Sound settings” F5-19.
. Display settings: Select the tab to set the screen settings. Refer to“ Display settings” F5-24.
. SUBARU STARLINK settings( if equipped): Select to the tab set the SUBARU STARLINK settings. Refer to“ SUBARU STARLINK settings” F5-25.
