3-46
Instruments and controls/Multi–function display (color LCD)
nance notifications, it turns yellow.
If there is a notification, the message will
be displayed. Take the appropriate actions
based on the message indicated.
NOTE
. You can set the self-check screen to
on or off. The default setting is off. For
details, refer to “On/Off setting” F3-59.
. After performing the maintenance,
change the setting of the correspond-
ing maintenance item. For details, refer
to “Maintenance settings” F3-58.
. The maintenance notification screen
will be displayed under either of the
following conditions.
– The period of time remaining
until the registered notification date
is 15 days or less.
– The total driving distance remain-
ing until the registered notification
distance is approximately 311 miles
(500 km) or less.
. The maintenance notification screen
will be displayed until either of the
following conditions is satisfied.
– The period of time passed after
the registered notification date is 15
days or more.
– The total distance driven after the
registered notification distance is
approximately 311 miles (500 km) or
more.
& Basic operation
& Interruption screen
Useful messages, such as reminder in-
formation, vehicle information, warning
information, etc. may interrupt the current
screen and appear on the display accom-
panied by a beep. Take proper action
according to the message.
Control switch (type A)
The warning screen will return to the
original screen after a few seconds.
Control switch (type B)
1) Up (select)
2) ENTER (push)
3) Down (select)
