3-44
Instruments and controls/Multi–function display (color LCD)
! Sonar Audible Alarm
The Reverse Automatic Braking system is
equipped with a function that emits a
warning sound when the system operates.
The function can be activated or deacti-
vated. Select “On” to set the warning
sound to active. Select “Off” to set the
warning sound to inactive.
! Default Settings
Select “Yes” to use the menu screen to
restore customized settings to the factory
default settings. Select “No” to return to
the previous screen without restoring to
the factory default settings.
Multi-function display (color
LCD)
WARNING
Always pay adequate attention to
safe driving when operating the
multi-function display while the ve-
hicle is in motion. When operation of
the multi-function display is disturb-
ing your awareness and ability to
concentrate on driving, stop the
vehicle in a safe place before per-
forming operations on the screen.
Also, do not concentrate on the
display while driving. Doing so may
cause you to look away from the
road and could result in an accident.
The multi-function display has the follow-
ing functions.
Description
Page
Displays useful messages,
such as warning information,
etc. 3-46
Displays basic screens (e.g.
fuel consumption screen, etc.) 3-47
Sets and adjusts maintenance
notification 3-58
Registers driving history 3-60
Sets and customizes car op-
eration 3-60
Reverse Automatic Braking
system (if equipped) 7-66
Also, use the multi-function display to set
and initialize the multi-function display
itself.
NOTE
. Illustrations show the display for
U.S.-spec. models as an example. For
models other than U.S.-spec. models,
elements in the illustrations (such as
the display indication and measure-
ment unit) may be different than the
ones for U.S.-spec. models.
. When the vehicle is in motion,
certain functions and selections may
not be available.
. The ima
