3-42
Instruments and controls/Combination meter display (color LCD)
The menu list is as follows.
Top menu Menu option Possible settings Screen Settings Welcome Good-bye Screen On or Off
Initial settings
On
Gauge Initial Movement On or Off On
Gear Position Indicator Setting (MT models) On or Off On
Languages Select the display language. The default language settings
vary depending on individual
countries. (For U.S. models:
English)
SRH (if equipped) ― On or Off On
REV settings (STI) REV Indicator Light On or Off Off
REV Alarm Level Engine Speed 2000 rpm - RED ZONE 2000 rpm
REV Buzzer On or Off Off
Warning Volume Max/Mid/Min Mid
Lead Vehicle Acquisition Sound On or Off On
Lead Vehicle Moving Monitor Function On or Off On
EyeSight Assist Monitor EyeSight Assist Monitor On or Off
Red indicator On
EyeSight Assist Monitor On or Off
Yellow indicator On
EyeSight Assist Monitor On or Off
Green indicator On
EyeSight (models with the
EyeSight system)
BSD/RCTA (if equipped) Warning Volume Max/Mid/Min/OFF Mid
RAB (models with the EyeSight
system) Warning Volume Max/Mid/Min Mid
Sonar Audible Alarm On or Off On
Default Settings ― Yes or No ―
