Seat, seatbelt and SRS airbags/Child restraint systems

1-31

. Store the head restraint that has
been removed in the cargo area.
Avoid placing the head restraint
in the passenger compartment to
prevent it from being thrown
around in the passenger compartment in a sudden stop or a
sharp turn.

colored unlocking marker which is
attached to the bottom of the lock
release knob is invisible. For details,
refer to “Folding down the rear seatback” F1-9.

Remove the covers and locate the lower
anchorages (bars).
3. Remove the rear seat head restraint.
For details, refer to “Head restraint adjustment” F1-8.
2. You will find marks “ ” at the bottom of
the rear seat seatbacks. These marks
indicate the positions of the lower anchorages (bars).

CAUTION
. When you install a child restraint
system, follow the manufacturer’s instructions supplied with
it. After installing the child restraint system, check to ensure
that it is held securely in position. If it is not held tight and
secure, the danger of your child
suffering personal injury in the
event of an accident may be
increased.

4. While following the instructions supplied by the child restraint system manufacturer, connect the lower hooks onto the
lower anchorages located at “ ” marks on
the bottom of the rear seatback. When the
hooks are connected, make sure the
adjacent seatbelts are not caught.

– CONTINUED –
