Starting and operating/Continuously variable transmission

7-25

! P (Park)
This position is for parking the vehicle and
starting the engine. In this position, the
transmission is mechanically locked to
prevent the vehicle from rolling freely.

this type of system.

& Select lever

When you park the vehicle, first apply the
parking brake firmly, then shift into the “P”
position. Do not hold the vehicle with only
the mechanical friction of the transmission.

1)

Select lever button

: With the brake pedal depressed, shift
while pressing the select lever button
in.
: Shift while pressing the select lever
button in.
: Shift without pressing the select lever
button.

The select lever has four positions, “P”,
“R”, “N”, “D” and it also has an “M” position
for using the manual mode.

NOTE
For some models, to protect the engine
while the select lever is in the “P” or
“N” position, the engine is controlled
so that the engine speed may not
become too high even if the accelerator
pedal is depressed hard.

To shift the select lever from the “P”
position to any other position, you should
depress the brake pedal fully then move
the select lever. This prevents the vehicle
from lurching when it is started.
! R (Reverse)
This position is for backing the vehicle. To
shift from the “N” to “R” position, stop the
vehicle completely then move the lever to
the “R” position while pressing the select
lever button in.
When the ignition switch has been turned
to the “LOCK”/“OFF” position, movement
of the select lever from the “N” to “R”
position is possible for a limited time
period by depressing the brake pedal,
and then it becomes impossible. For
details, refer to “Shift lock function” F7-28.

– CONTINUED –
