7-22

Starting and operating/Driver’s Control Center Differential (C.DIFF/DCCD) (STI)

& Manual mode

In the manual mode, you can use the
center differential control switch to adjust
the initial LSD torque as desired. When
this mode is selected, the “AUTO” indicator disappears.

! Center differential control switch
and indicator

The control switch is located beside the
parking brake lever. By pushing the
control switch forward or pulling it rearward, it is possible to change the initial
LSD torque.
The center differential indicator on the
combination meter gives six levels of
indication. The indicator and control
switch are linked; when the switch is
pushed or pulled to change the initial
LSD torque, the indicator changes accordingly.

Push the switch forward to increase the
initial LSD torque; when the “LOCK”
indicator appears, the initial LSD torque
setting is maximum. The center differential
will then be almost comple tely locked.
