6-16

Interior equipment/Rear view camera

CAUTION
. When moving backward, always
check the back with your eyes
without relying on the help lines.
. The actual position may be different from the indication of the
help lines.
. Differences may occur due to
number of passengers or loaded
cargo.
. When the vehicle is on a slope or
when the vehicle is inclined
against the road, the indication
is different from the actual position.
. Be sure to observe the displayed
warning message of “Check Surroundings Before Backing Up”.

NOTE
If you shift to the “R” range within
several seconds after turning on the
ignition switch, the warning message
may not be displayed. Wait for several
seconds after turning on the ignition
switch before shifting to the “R” range.
The warning message will then be
displayed.

! Difference between screen image
and actual road
The distance markers show the distance
for a level road when the vehicle is not
loaded. It may be different from the actual
distance depending on the loading conditions or road conditions.

! When there is an upward slope at
the back

1)

3 feet (1 m)

The distance on the screen looks farther
than the actual distance.
