Subaru WRX & WRX STI Manuals 2017 WRX & WRX STI Owner’s Manual | Page 259

4-8

Climate control/Manual climate control operation

. Turn the passenger’s side temperature
control dial
The “DUAL” mode can be canceled by
pressing the “DUAL” button.
When the “DUAL” mode is selected:
Turn the driver’s side dial to set the
driver’s side temperature. Turn the front
passenger’s side dial to set the front
passenger’s side temperature.
When the “DUAL” mode is canceled:
Set the desired temperature by turning the
driver’s side dial.
When the “DUAL” mode is canceled, only
the driver’s side temperature is displayed.

& Fan speed control
The fan operates only when the ignition
switch is in the “ON” position. Select the
preferred fan speed by turning the fan
speed control dial.

& Air conditioner control
The air conditioner operates only when
the engine is running.
Press the air conditioner button while the
fan is in operation to turn on the air
conditioner. When the air conditioner is
on, the “A/C” indicator light illuminates.
To turn off the air conditioner, press the

button again.

dusty.

NOTE
For efficient defogging or dehumidifying in cold weather, turn on the air
conditioner. However, if the ambient
temperature decreases to approximately 328F (08C), the air conditioner
compressor will stop operating.

& Air inlet selection
Select the air inlet by pressing the air inlet
selection button.
ON position (recirculation): Interior air is
recirculated inside the vehicle. Press the
air inlet selection button to the ON position
for fast cooling with the air conditioner or
when driving on a dusty road.
OFF position (outside air): Outside air is
drawn into the passenger compartment.
Press the air inlet selection button to the
OFF position when the interior has cooled
to a comfortable temperature and the road
is no longer dusty.

WARNING
Continued operation in the ON position may fog up the windows. Switch
to the OFF position as soon as the
outside conditions are no longer

NOTE
When the battery is disconnected or
the battery voltage drops, the air inl et
selection operation indicator light may
blink. This does not indicate a malfunction. However, if the indicator light
blinks every time you start the engine,
a malfunction may occur in the electrical circuit. Have the vehicle inspected at the nearest SUBARU dealer.
