Subaru WRX & WRX STI Manuals 2017 WRX & WRX STI Owner’s Manual | Page 188
Instruments and controls/Multi function display
following conditions.
– The period of time remaining
until the registered notification date
is 15 days or less.
– The total driving distance remaining until the registered notification
distance is approximately 311 miles
(500 km) or less.
. The maintenance notification screen
will be displayed until either of the
following conditions is satisfied.
– The period of time passed after
the registered notification date is 15
days or more.
– The total distance driven after the
registered notification distance is
approximately 311 miles (500 km) or
more.
3-53
& Interruption screen
& Basic screens
Useful messages, such as reminder information, vehicle information, warning
information, etc. may interrupt the current
screen and appear on the display accompanied by a beep. Take proper action
according to the message.
These are the basic screens of the multi
function display.
The warning screen will return to the
original screen after a few seconds.
Item
Page
Information bar
3-54
Boost pressure + accelerator
opening ratio screen
3-55
Fuel consumption screen
3-56
ECO history screen
3-56
Vehicle activation status
screen
3-56
Triple meter screen
3-57
Guidance screen
3-58
Clock/calendar screen
3-58
By operating the “ ” or “ ” of the control
switch, you can switch the screen that is
always displayed. Also, when the
button is pushed and held, the selection
screen can be displayed. For details about
the selection screen, refer to “Selection
screen” F3-60.
– CONTINUED –
