Subaru WRX & WRX STI Manuals 2017 WRX & WRX STI Owner’s Manual | Page 182
Instruments and controls/Multi information display
3-47
The menu list is as follows.
Top menu
Menu option
Possible settings
Initial settings
Screen Settings
Welcome Good-bye Screen
On or Off
On
Gauge Initial Movement
REV settings (STI)
On or Off
On
Gear Position Indicator Setting (MT On or Off
models)
On
Languages
Select the display language.
The default language settings vary
depending on individual countries.
(For U.S. models: English)
REV Indicator Light
On or Off
Off
REV Alarm Level Engine Speed
2000 rpm - RED ZONE
2000 rpm
REV Buzzer
On or Off
Off
Warning Volume
Max/Mid/Min
Mid
Lead Vehicle Acquisition Sound
On or Off
On
Lead Vehicle Moving Monitor
Function
On or Off
On
RAB (models with EyeSight system)
Warning Volume
Max/Mid/Min
Mid
Sonar Audible Alarm
On or Off
On
BSD/RCTA (if equipped)
Warning Volume
Max/Mid/Min/OFF
Mid
Default Settings
―
Yes or No
―
EyeSight (models with EyeSight
system)
– CONTINUED –
