Subaru WRX & WRX STI Manuals 2017 WRX & WRX STI Owner’s Manual | Page 172

Instruments and controls/Warning and indicator lights

& REV indicator light
(STI)

This indicator light illuminates when the
engine speed reaches the level that was
previously set. This indicator light also
flashes when the tachometer needle enters the red zone. For details, refer to
“REV indicator light and buzzer (STI)” F312.

& Steering responsive

fog lights warning indicator/Steering responsive fog lights OFF indicator (if equipped)

NOTE
For details about the steering responsive fog lights system, refer to “Steering responsive fog lights system” F3101.
! Steering responsive fog lights
warning indicator
This indicator starts blinking when the
steering responsive fog lights system
malfunctions. When this indicator appears
while the system is activated, contact your
SUBARU dealer for an inspection.

! Steering responsive fog lights OFF
indicator
This indicator appears when the steering
responsive fog lights system is deactivated. This indicator disappears when the
system is activated.

& RAB warning light (if

& BSD/RCTA warning in-

& RAB OFF indicator

dicator (if equipped)

This warning indicator appears when the
BSD/RCTA is malfunctioning. In this case
the BSD/RCTA warning indicator will be
shown on the multi information display of
the combination meter. When this indicator appears, have your vehicle inspected
by your SUBARU dealer as soon as
possible.

& BSD/RCTA OFF indicator (if equipped)

The indicator appears when the BSD/
RCTA OFF switch is pressed to deactivate
the BSD/RCTA. In this case the BSD/
RCTA OFF indicator will be shown on the
multi information display of the combination meter. For details, refer to “BSD/
RCTA” F7-55.

3-37

equipped)

This indicator illuminates if the Reverse
Automatic Braking System malfunctions.
Refer to “Reverse Automatic Braking
System” F7-64.

light (if equipped)

This indicator illuminates when the Reverse Automatic Braking System is turned
OFF, or when the Reverse Automatic
Braking System is suspended temporarily.
Refer to “Reverse Automatic Braking
System” F7-64.
