Instruments and controls/Warning and indicator lights

but it turns off while driving.
. The warning light illuminates during
driving, but it turns off immediately and
remains off.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warning light may illuminate. This is due to the low battery voltage
and does not indicate a malfunction.
When the battery becomes fully charged,
the light will turn off.

& Brake system
warning light

WARNING
. Driving with the brake system
warning light on is dangerous.
This indicates your brake system
may not be working properly. If
the light remains illuminated,
have the brakes inspected by a
SUBARU dealer immediately.
. If at all in doubt about whether
the brakes are operating properly, do not drive the vehicle.
Have your vehicle towed to the
nearest SUBARU dealer for repair.
. If the brake system warning light
illuminates, the electronic park-

ing brake system may be malfunctioning. Immediately stop
your vehicle in a safe location,
use tire stops under the tires to
prevent the vehicle from moving
and contact your SUBARU dealer. For details, refer to “Electronic parking brake (models with
electronic parking brake system)” F7-44.

NOTE
. Even if the brake system warning
light illuminates, if the warning light
behavior is as described in the following examples, the electronic parking
brake system is not malfunctioning.
– The warning light turns off when
the electronic parking brake is applied or released.
– The warning light turns off when
the ignition switch is turned to the
“ON” position again.
. The brake system warning light may
illuminate immediately after the engine
is started. However, it is not malfunctioning if the warning light turns off
after the electronic parking brake is
released.
. The brake system warning light may
illuminate after the electronic parking

3-21

brake is frequently applied and released. However, the electronic parking
brake system is not malfunctioning if
the light turns off for a short period of
time.
. When the engine is started while the
electronic parking brake is applied/
released, the system may judge an
abnormal situation and the warning
light may illuminate. If the warning light
illuminates, turn the ignition switch
once to the “LOCK/OFF” position and
then restart the engine. Then, apply/
release the electronic parking brake. If
the warning light turns off, the system
will be restored.
This light has the following functions.
! Parking brake indicator (models
without electronic parking brake
system)
This light illuminates with the parking
brake applied while the ignition switch is
in the “ON” position. It turns off when the
parking brake is fully released.
! Brake fluid level warning
This light illuminates when the brake fluid
level has dropped to near the “MIN” level
of the brake fluid reservoir with the ignition
switch in the “ON” position and with the
parking brake fully released.
– CONTINUED –
