Subaru WRX & WRX STI Manuals 2016 WRX & WRX STI Owner’s Manual | Page 407

7-18

Starting and operating/Manual transmission

& Shifting speeds

the driver about the upshift timing.

! Recommended shifting speeds
The best compromise between fuel economy and vehicle performance during
normal driving is ensured by shifting up
at the speeds listed in the following table.

The shift-up indicator can be activated or
deactivated. For details, refer to “Shift-up
indicator (STI)” F3-34.
! Maximum allowable speeds
The following table shows the maximum
speeds that are possible with each different gear. The tachometer’s needle will
enter the red area if these speeds are
exceeded.
With the exception of cases where sudden
acceleration is required, the vehicle
should not be driven with the tachometer’s
needle inside the red area. Failure to
observe this precaution can lead to
excessive engine wear and poor fuel
economy.

Shift up

mph (km/h)

1st to 2nd

15 (24)

2nd to 3rd

25 (40)

3rd to 4th

40 (64)

4th to 5th

45 (72)

5th to 6th

50 (80)

! Shift-up indicator (STI)

Gear

STI
mph (km/h)

Except STI
mph (km/h)

1st

31 (50)

31 (49)

2nd

51 (82)

55 (88)

WARNING

The shift-up indicator appears to inform

When shifting down a gear, ensure
that the vehicle is not travelling at a
speed exceeding the Maximum Allowable Speed for the gear which is
about to be selected. Failure to
observe this precaution can lead to

engine over-revving and this in turn
can result in engine damage.
In addition, sudden application of
engine brakes when the vehicle is
travelling on a slippery surface can
lead to wheel locking; as a consequence, control of the vehicle may
be lost and the risk of an accident
increased.

NOTE
Never exceed the posted speed limit.

& Driving tips
Do not drive with your foot resting on the
clutch pedal and do not use the clutch to
hold your vehicle at a standstill on an
upgrade. Either of those actions may
cause clutch damage.
Do not drive with your hand resting on the
shift lever. This may cause wear on the
transmission components.
When it is necessary to reduce vehicle
speed due to slow traffic, turning corners,
or driving up steep hills, downshift to a
lower gear before the engine starts to
labor.
On steep downgrades, downshift the
transmission to 5th, 4th, 3rd or 2nd gear
