3-12

Instruments and controls/REV indicator light and buzzer (STI)

& ECO gauge

NOTE
. The ECO gauge shows only an
approximate indication.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until driving 0.6 mile (1 km).
Until that time, the ECO gauge does not
operate.

REV indicator light and buzzer (STI)

The unit displayed varies depending on the
models.

The ECO gauge shows the difference
between the average rate of fuel consumption since the trip meter was last
reset and the current rate of fuel consumption.

1)

REV indicator light

MPG

Better

Poorer

The REV alarm system has the following
functions.
. When the engine speed reaches the
level that was previously set, the REV
indicator light illuminates to inform you. At
this time, a buzzer also sounds if the
buzzer setting is activated.
. Whenever the engine speed enters the
red zone of the tachometer, the REV
indicat
