Subaru WRX & WRX STI Manuals 2015 WRX & WRX STI Owner's Manual | Page 287

5-34

Audio/Bluetooth® audio

NOTE

NOTE

You cannot set Bluetooth® audio while
driving.

After the ignition switch is turned to the
“LOCK”/“OFF” position, the registered
device will not be automatically connected to the system even if the
ignition switch is turned to the “ACC”
or “ON” position.

! Registering (pairing) device

NOTE
Only one device can be registered. If
you want to register another device,
delete the previously registered device
and then perform the registering procedure. For details about deleting a
device, refer to “Deleting device” F534.
1. Select the “PAIR AUDIO” menu.
– If a device is already registered,
“MEMORY FULL” will be displayed
and the mode will change to the
Bluetooth® audio setting mode.
2. After the passkey is shown on the
display, input the passkey into the device.
– If you input the correct passkey,
“PAIRED” will be displayed and the
registration procedure will be finished.
– If you input an incorrect passkey,
“FAILED” will be displayed, the registration procedure was not successful
and the mode will change to the
Bluetooth® audio setting mode.

! Selecting device
1. Select the “SELECT AUDIO” menu.
– If no devices are registered,
“EMPTY” will be displayed and the
mode will change to the Bluetooth®
audio setting mode.
2. Select the “CONFIRM” menu.
– If the device is connected, “SELECTED” will be displayed and the
selection procedure will be finished.
– If the device cannot be connected,
“FAILED” will be displayed and the
selection procedure will not be successful.

– The new passkey will be displayed,
the passkey will be changed and the
mode will change to the Bluetooth®
audio setting mode.
! Deleting device
1. Select the “DELETE AUDIO” menu.
– If no devices are registered,
“EMPTY” will be displayed and the
mode will change to the Bluetooth®
audio setting mode.
2. Select the “CONFIRM” menu.
– “DELETED” will be displayed and
the mode will change to the Bluetooth® audio setting mode.

& Bluetooth® audio operation
NOTE
Depending on the connected device, it
may not activate as per the following
items or not work smoothly.

! Setting passkey

! How to play back

1. Select the “SET PASSKEY” menu.
– After the currently set passkey is
displayed, a new passkey can be
entered.
2. Input the new passkey by operating
the “TRACK” dial.
3. Select the “CONFIRM” menu.

The following information will be displayed while playing Bluetooth® audio.
. Album name
. Artist name
. Song title

NOTE

For details, refer to “Audio screen” F3-
