Audio/Power and audio controls

Power and audio controls
& Power switch and volume
control

! Tone and balance control
Sound control dial:

Power and volume
control dial
Type B audio

& Sound controls and audio
settings
NOTE

The control function returns to the tune/
track control mode after approximately 8
seconds.

NOTE
Type A audio

The dial is used for both power (ON/OFF)
and volume control. The radio is turned
ON and OFF by pressing the dial, and the
volume is controlled by turning the dial.

5-7

Each brief press of the sound control dial
changes the control modes in the following sequence.

. VIRTUAL BASS compensates for
low pitch.
. SND RESTORER compensates for
high pitch.
. VOCAL IMAGE controls the sound
image localization.
! Other settings

“MENU” button

Each brief press of the “MENU” button
changes the control modes in the following sequence.

This feature can be set via the multi
function display unit. For details, refer
to “Sound setting” F3-94.

Type A audio:

*: Except harman/kardon audio

Choose the preferred level for each mode
by turning the sound control dial.
– CONTINUED –
