Subaru WRX & WRX STI Manuals 2015 WRX & WRX STI Owner's Manual | Page 178

Instruments and controls/Multi function display

! Triple meter screen

Item

Details

3-53

! Guidance screen

Average vehicle speed (Average
vehicle speed for the entire driving
time from when the trip meter was
reset)
Lifetime fuel consumption
Engine oil temperature (except
STI)
Accelerator opening ratio

Triple meter screen (display example)

This screen displays up to three optional
pieces of information that can be selected
from the following items.
The items shown in the triple meter screen
can be changed. For details, refer to
“Triple meter setting” F3-73.

Journey distance (the distance
that has been driven since the
ignition switch was turned to the
“ON” position)
Average fuel consumption for the
entire driving distance from when
the ignition switch was turned to
the “ON” position

When the
button is pushed and held,
the selection screen can be displayed.
The displayed contents can be set or
customized from the selection screen. For
details, refer to “Selection screen” F3-56.

Boost pressure

– CONTINUED –
