Instruments and controls/Multi information display
4)
5)
6)
7)

Warning indicator
Select lever/gear position indicator (refer
to “Select lever/gear position indicator
(CVT models)” F3-31.)
SI-DRIVE indicator light (refer to “SIDRIVE indicator” F3-31.)
Odometer (refer to “Odometer” F3-9.)/
double trip meter (refer to “Double trip
meter” F3-9.)

& Welcome screen

3-35

Good-bye Screen” F3-44.

& Good-bye screen

& Basic operation
By operating “ ” or “ ” of the control
switch, the screens and selection items
can be switched. When the “ /SET”
switch is pulled toward you, the item can
be selected and set.
If there are some useful messages, such
as vehicle information, warning information, etc., they will interrupt the current
screen, and appear on the display accompanied by a beep. If such a screen is
displayed, take proper action according to
the message shown on the screen.

When the door is unlocked, and the
driver’s door is opened and then closed,
the welcome screen will appear for approximately 20 seconds.

NOTE
. Once the welcome screen appears,
it takes a certain period of time to
display it again.
. The welcome screen will disappear
when the ignition switch is turned to
the “ON” position while the welcome
screen is displayed.
. If any of the doors is opened while
the welcome screen is displayed, the
door ajar warning will appear.
. The welcome screen can be set to
on or off. For details, refer to “Welcome

If the ignition switch is turned to the
“LOCK”/“OFF” position, the “Good-bye”
screen will appear for approximately 3
seconds.

– CONTINUED –
