Subaru WRX & WRX STI Manuals 2015 WRX & WRX STI Owner's Manual | Page 118

Keys and doors/Windows

& Power window operation by
driver

! Operating the driver’s window

! Driver’s side power window
switches

2-29

This switch also has a one-touch auto up
feature that allows the window to be
closed fully without holding the switch.
Pull the switch up until it clicks and release
it, and the window will fully close. To stop
the window halfway, push the switch down
lightly.

NOTE

1)
2)

1)
2)
3)
4)
5)

Lock switch
For driver’s window (with one-touch auto
up and down feature)
For front passenger’s window
For rear left window
For rear right window

All door windows can be controlled by the
power window switch cluster at the driver
side door.

Automatically open/close
Open/close

To open:
Push the switch down lightly and hold it.
The window will open as long as the
switch is held.
This switch also has a one-touch auto
down feature that allows the window to be
opened fully without holding the switch.
Push the switch down until it clicks and
release it, and the window will fully open.
To stop the window halfway, pull the
switch up lightly.
To close:
Pull the switch up lightly and hold it. The
window will close as long as the switch is
held.

. If the vehicle’s battery is disconnected due to situations such as
battery or fuse replacement, the onetouch auto up/down function is deactivated. Initialize the power window to
reactivate the one-touch auto up/down
function. Refer to “Initialization of
power window” F2-32.
. When the following operations are
performed, the power window breaker
will operate and it may not be possible
to open or close the window.
– After the driver’s side window is
fully closed or fully opened, the
switch continues to be operated in
the same direction for a few seconds.
– After the windows for three or
more seats are fully closed or fully
opened, each switch continues to
be operated in the same direction
simultaneously for a few seconds.
In this case, after the breaker recovers,
– CONTINUED –
