1-34

Seat, seatbelt and SRS airbags/*SRS airbag (Supplemental Restraint System airbag)

Please contact your SUBARU dealer if
you have any question regarding the
installation of a child restraint system.

CAUTION
Always remove the head restraint
when mounting a child restraint
system with a top tether. Otherwise,
the top tether cannot be fastened
tightly.

*SRS airbag (Supplemental
Restraint System airbag)
*SRS: This stands for supplemental restraint system. This name is used because the airbag system supplements the
vehicle’s seatbelts.
Your vehicle is equipped with a crash
sensing and diagnostic module, which will
record the use of the seatbelt by the front
passenger when any of the SRS frontal,
side and curtain airbags deploys.
Your vehicle is equipped with a supplemental restraint system in addition to a
lap/shoulder belt at each front seating
position and each rear window-side seating positions. The supplemental restraint
system (SRS) consists of six airbags.
The configurations are as follows.
. Driver’s and front passenger’s frontal
airbags
. Driver’s and front passenger’s side
airbags
. Curtain airbags (for driver, front passenger, and window-side rear passengers)
These SRS airbags are designed only
to be a supplement to the primary
protection provided by the seatbelt.

The system also controls front seatbelt
pretensioners. For operation instructions
and precautions concerning the seatbelt
pretensioner, refer to “Front seatbelt pretensioners” F1-19.

& General precautions regarding SRS airbag system
WARNING
. To obtain maximum protection in
the event of an accident, the
driver and all passengers in the
vehicle should always wear seatbelts when the vehicle is moving.
The SRS airbag is designed only
to be a supplement t
