Maintenance and service/Replacement of wiper blades

carefully return the wiper arms
on the windshield by hand. You
should not return the wiper arms
to the windshield only by the
return spring. Otherwise, the wiper arms may be deformed and/
or the windshield surface may be
scratched.

& Windshield wiper blade assembly

11-33

! Type B
1. Raise the wiper arm off the windshield.

! Type A
1. Raise the wiper arm off the windshield.

If you cannot eliminate the streaking even
after following this method, replace the
wiper blades using the following procedures.

1)
2)
1)

Stopper

2. Remove the wiper blade assembly by
holding its pivot area and pushing it in the
direction shown by the arrow while depressing the wiper blade stopper.
3. Install the wiper blade assembly to the
wiper arm. Make sure that it locks in place.
4. Hold the wiper arm by hand and slowly
lower it in position.

Open the cover
Pull down the wiper blade

2. Remove the wiper blade assembly by
opening the cover and pulling it down in
the direction shown in the illustration.
3. Install the wiper blade assembly to the
wiper arm. Make sure that it locks in place.
4. Hold the wiper arm by hand and slowly
lower it in position.

– CONTINUED –
