Subaru WRX & WRX STI Manuals 2014 Impreza WRX & WRX STI Owner's Manual | Page 229

5-46

Audio/Hands–free system

hold the ON hook switch
! Ending a call
Press the ON hook switch
! Volume control

& Bluetooth® setting

.

! Security setting
After selecting the “SECURITY” menu,
perform the following procedures.

.

! Setting PIN code
The PIN code is a 4-digit number and is
used when locking the phonebook.

You can adjust the phone call volume, the
voice volume and the voice guidance
volume. Refer to “Volume control buttons”
F5-32.
! Adjustable level of each volume
Volume

Range

Phone call

0 to 14

Initial setting
7

Voice

0 to 14

7

Voice guidance

0 to 6

3

1. Select the “SET PIN” menu.
– Then “CURRENT PIN?” is displayed.
2. Input the current PIN code by performing either of the following procedures.
– Operate the “TUNE/TRACK/CH”
dial.
and say
– Press the talk switch
the number.
3. Select the “CONFIRM” menu.
4. Input the new PIN code by performing
either of the following procedures.
– Operate the “TUNE/TRACK/CH”
dial.
and say
– Press the talk switch
the number.
5. Select the “CONFIRM” menu.
! Locking the phonebook
1. Select “PHBK LOCK” by operating the
“TUNE/TRACK/CH” dial or say “PHONEBOOK LOCK”.

– Then “CURRENT PIN?” is displayed.
2. Input the PIN code by performing
either of the following procedures.
– Operate the “TUNE/TRACK/CH”
dial.
– Press the talk switch
and say
the number.
3. Select the “CONFIRM” menu.
– If the inputted PIN code is correct,
“LOCKED” is displayed and the phonebook is locked.

NOTE
While the phonebook is locked, if the
operation restricted menu is selected,
“PHBK LOCK” is displayed.
! Unlocking the phonebook
1. Perform either of the following procedures.
– Select the “PHBK UNLOCK” menu
by operating the “TUNE/TRACK/CH”
dial.
and say
– Press the talk switch
“PHONEBOOK UNLOCK”.

NOTE
If the phonebook is not locked, “UNLOCK” is displayed and the mode
changes to the security mode.
