Subaru WRX & WRX STI Manuals 2014 Impreza WRX & WRX STI Owner's Manual | Page 207
5-24
Audio/Precautions to observe when handling a compact disc
in the center console. A stereo mini pin
plug (3.5ø) can be inserted in this jack.
The connection cable is available at
electrical appliance or similar stores.
To use the AUX input jack:
1. Connect a portable audio player to the
AUX input jack.
Type A audio
Type B audio
2. Press the AUX input selection button
“CD/AUX” on the audio control panel to
turn on the auxiliary audio input.
3. Play back the portable audio player.
Refer to the Owner’s Manual of the
portable audio player.
NOTE
. The AUX jacks of the models with
the genuine SUBARU navigation system are the RCA type. For detailed
information, refer to the Owner’s Manual supplement for the navigation system.
. The output sound of the portable
audio player is not loud, and the sound
via the vehicle’s speakers that are
connected to the vehicle audio set
may be very low. If you turn up the
volume of the audio set, the volume
becomes louder. However, when you
change from one portable audio player
to another one, the volume levels via
the vehicle’s speakers may be significantly louder compared to the prior
device. To avoid a large volume difference, turn down the volume when you
change between portable audio
players.
. In some cases, when the sound
volume of the portable audio player is
low, sound quality may become impaired when you turn up th e volume of
the vehicle audio system. In this case,
adjust the sound volume of the portable audio player.
. In some cases, noise occurs because of a bad connection between the
portable player and the audio system.
Try cleaning the stereo jack and audio
plug.
. If the noise is not reduced, check for
disconnection of the cord or a malfunction of the portable player.
Precautions to observe when
handling a compact disc
Use only compact discs (CDs, CD-Rs and
CD-RWs) that have the mark shown in the
following. Also, some compact discs
cannot be played.
