3-44

Instruments and controls/Mirrors

6. When the indicator light flashes slowly
and then rapidly after several seconds,
release both buttons.
7. Plug the motor of the entrance gate/
garage door opener to the outlet.
8. Test your entrance gate/garage door
opener by pressing the programmed
HomeLink® button.

1)
2)
3)

HomeLink® button 1
HomeLink® button 2
HomeLink® button 3

2. Press and hold the two outer
HomeLink® buttons (button 1 and button
3) until the HomeLink® indicator light
begins to flash (after approximately 20
seconds). Then release both buttons.
3. Hold the end of the entrance gate’s/
garage door opener’s hand-held transmitter between 1 and 3 inches (25 and 76
mm) away from the HomeLink® button you
wish to program.
4. Press and hold the desired HomeLink®
button.
5. Press and release (“cycle”) the handheld transmitter button every 2 seconds
until step 6 is complete.

! Operating the HomeLink® Wireless Control System
Once programmed, the HomeLink® Wireless Control System can be used to
remote-control the devices F
