Instruments and controls/Meters and gauges

NOTE
If the connection between the combination meter and battery is broken for any
reason such as vehicle maintenance or
fuse replacement, the data recorded on
the trip meter will be lost.

& Fuel gauge

3-9

seconds or (b) open and close the driver’s
door, the fuel gauge indication will turn off.

NOTE

& Tachometer
The tachometer shows the engine speed
in thousands of revolutions per minute.

CAUTION
Do not operate the engine with the
pointer of the tachometer in the red
zone. This may cause severe damage to the engine.

1)

Low fuel warning light (Refer to “Low fuel
warning light” F3-20.)

The fuel gauge shows the approximate
amount of fuel remaining in the tank.
When the ignition switch is in the “LOCK”
or “Acc” position, the fuel gauge shows “E”
even if the fuel tank contains fuel.
The gauge may move slightly during
braking, turning or acceleration due to fuel
level movement in the tank.
If you press the t ɥ
