Instruments and controls

NOTE
Even if the REV alarm system is not set,
the REV indicator light will flash whenever the engine speed enters the red
zone of the tachometer.

3-11

again. The number will change sequentially from 2 to 7. Release your finger at
the desired alarm-level engine speed.

& Setting the alarm-level engine speed
The alarm-level engine speed can be set
(in 100 rpm steps) within the range from
2,000 rpm to 7,000 rpm as follows.
1. Push the trip knob to select “REV” on
the combination meter.

2. When the trip knob is pushed for more
than 2 seconds, the thousands place
flashes.
3. Release your finger from the trip knob
once, then push and hold the trip knob

4. When the trip knob is pushed, the
hundreds place flashes.
5. Release your finger from trip knob
once, then push and hold the trip knob
again. The number will change sequentially from 0 to 9. Release your finger at
the desired alarm-level engine speed.
6. When the trip knob is pushed, the
buzzer sounds and the REV alarm system
will automatically enter its new setting
mode (step 7 below), in which you can
activate or deactivate the buzzer.

7. Every time that the trip knob is pushed
and held, the buzzer changes to activate
or deactivate.
b – on: Activated
b – off: Deactivated
When the mode is changed to “activate”,
the buzzer sounds.
8. Push the trip knob to complete the
setting procedure.

NOTE
. The IX
