3-6

Instruments and controls

& Canceling the function for
meter/gauge needle movement upon turning on the
ignition switch

. It is not possible to cancel the initial
movement setting of the meter/gauge
needles when the ignition switch is in
the “ON” position. Cancel the setting
when the ignition switch is in the
“LOCK” or “Acc” position.

& Meter/Gauge needle illumination setting (except STI)
When the setting is activated or deactivated, the meter needles and gauge
needles illuminate and turn off as follows.

It is possible to activate or deactivate the
movement of the meter needles and
gauge needles that takes place when the
ignition switch is turned to the “ON”
position.
Turn the ignition switch to the “LOCK” or
“Acc” position.
Press the trip knob to show “ ” or “
”
on the odometer and trip meter display.
The display can be switched as shown in
the following illustration by pressing the
trip knob.

*1: STI only
*2: “ ” or “
”, and “
” or “
”
cannot be displayed when the ignition
switch is in the “ON” position.
*3: Except STI
To change the current setting, press the
trip knob for at least 2 seconds.
: Activated
: Deactivated

NOTE
. Your vehicle’s initial movement
setting of the meter/gauge needles
has been set for activation “ ” at the
time of shipment from the factory.

Activated:
When the driver’s door is opened while
the ignition switch is in the “LOCK”
position, the needles illuminate and turn
off after approximately 20 seconds. The
illumination of the needles gradually turns
off after the ignition switch is turned from
the “ON” position to the “LOCK” position.
Deactivated:
The needles do not illuminate when the
driver’s door is opened while the ignition
switch is in the “LOCK” position. The
illumination of the needles turns off immediately after the ignition switch is turned
from the “ON” position to the “LOCK”
position.
