4-4

Climate control

! Fan speed control dial
The fan operates only when the ignition
switch is turned to the “ON” position. The
fan speed control dial is used to select
four fan speeds.
! Airflow control dial
Each dial position activates the following
air outlets.
(Ventilation): Instrument panel outlets
(Bi-level): Instrument panel outlets and
foot outlets
(Heat): Foot outlets, both side outlets of
the instrument panel and some through
windshield defroster outlets (A small
amount of air flows to the windshield and
both side windows to prevent fogging.)

less of the position of the air conditioner button to defog the windshield
more quickly. However the indicator on
the air conditioner button will not
illuminate. At the same time, the air
inlet selection is automatically set to
“outside air” mode.
In this state, you cannot select “recirculation” mode by manually pressing
the air inlet selection button.
Also, you cannot stop the air conditioner compressor by pressing the air
conditioner button.

ON position (recirculation): Interior air is
recirculated inside the vehicle. Push the
air inlet selection button to the ON position. The indicator light will illuminate.
Place the air inlet selection button to F
