Starting and operating

“LOCK” position and remove the key from
the ignition key cylinder.
. If the ignition switch is turned to the
“LOCK” position while the select lever is in
the “N” position, the select lever may not
be moved to the “P” position after a period
of time. Therefore, move the select lever
to the “P” position with the brake pedal
depressed soon after the ignition switch is
turned to the “LOCK” position.
! Shift lock release
If the select lever cannot be operated, turn
the ignition switch back to the “ON”
position then move the select lever to the
“P” position with the brake pedal depressed.
If the select lever does not move after
performing the above procedure, perform
the following steps.
. When the select lever cannot be
shifted from “P” to “N”:
Refer to “Shift lock release using the shift
lock release button” F7-25.
. When the select lever cannot be
shifted from “N” to “R”, “P”:
Within 60 seconds after placing the ignition switch in the “Acc” position, move the
select lever to the “R” or “P” position with
the brake pedal depressed.

If you must perform the above procedure,
the shift lock system (or the vehicle control
system) may be malfunctioning. Contact a
SUBARU dealer for an inspection as soon
as possible.
If the select lever does not move after
performing the above procedure, refer to
“Shift lock release using the shift lock
release button” F7-25.
! Shift lock release using the shift
lock release button
Perform the following procedure to release
the shift lock.
1. Apply the parking brake and stop the
engine.

7-25

cover.

NOTE
To prevent damage to the shift lock
cover, cover the tip of the flat-head
screwdriver with vinyl tape or a cloth
before removing the cover.

3. While depressing the brake pedal,
insert a screwdriver into the hole, press
the shift lock release button using a
screwdriver, and then move the select
lever.

2. Remove the shift lock cover using a
flat-head screwdriver. The shift lock release button is located under the shift lock

If the select lever does not move after
performing the above procedure, the shift
lock system may be malfunctioning. Contact a SUBARU dealer for an inspection
as soon as possible.
– CONTINUED –
